SOLO CHAMBER SUMMARY
Chamber Footprint:
1 x HBOT Chamber: Width 91 inches * Depth 35 inches
1 x Control Unit: Height 43 inches * Width 21 inches * Depth 19 inches
1 x Oxygen Concentrator (each): Height 27 inches * Width 14 inches * Depth 34 inches 1 x AC Unit: Height 22 inches * 15 inches * Depth 26 inches
Design note, the oxygen concentrators can be stored up to 20 meters away to reduce the
footprint required and reduce decibel levels. Equipment Weight:
1 x HBOT Chamber: 135kg
1 x Control Unit: 90kg
1 x Oxygen Concentrator (each): 71kg 1 x AC Unit: 30kg
Electrical Load
Chamber and Control Panel (1 Power Point Supply) Electric Voltage: 220V
Maximum Absorbed Power: 8A Peak Period 1s
Concentrators (1 Power Point Supply)
Electric Voltage: 220V
Maximum Absorbed Power: 8A Peak Period 1s each
AC Chiller (1 Power Point Supply)
Electric Voltage: 220V
Maximum Absorbed Power: 6A Peak Period 1s
One Hype DUO Chamber
DUO CHAMBER SUMMARY Equipment Footprint Chamber Footprint: 1 x HBOT Chamber: Width 87 inches * Depth 77 inches 1 x Control Unit: Height 43 inches * Width 21 inches *
