DUO CHAMBER SUMMARY
Equipment Footprint
Chamber Footprint:
1 x HBOT Chamber: Width 87 inches * Depth 77 inches
1 x Control Unit: Height 43 inches * Width 21 inches * Depth 19 inches
2 x Oxygen Concentrator (each): Height 27 inches * Width 14 inches * Depth 34 inches
1 x AC Unit: Height 22 inches * 15 inches * Depth 26 inches
Design note, the oxygen concentrators can be stored up to 20 meters away to
reduce the footprint required and reduce decibel levels.
Electrical Load
Chamber and Control Panel (1 Power Point Supply) Electric Voltage: 230V
Maximum Absorbed Power: 14A Peak Period 1s
Concentrators (2 of these into 2 Power Point Supply) Electric Voltage: 230V
Maximum Absorbed Power: 8A Peak Period 1s each
AC Chiller (1 Power Point Supply)
Electric Voltage: 230V
Maximum Absorbed Power: 8A Peak Period 1s
Chamber Weight
Chamber – 650kg
Control Panel – 80kg
AC Chiller – 43kg
2 x Oxygen Concentrators – 71kg each = 142kg
One Hype SOLO Chamber
SOLO CHAMBER SUMMARY Chamber Footprint: 1 x HBOT Chamber: Width 91 inches * Depth 35 inches 1 x Control Unit: Height 43 inches * Width 21 inches * Depth 19
